Vacuum Packing Machine
The horizontal vacuum packaging model is suitable for various heat-sealing multi-layer composite films. It is specially designed for the vacuum packaging requirements of food and other products. It can automatically complete the bag forming, making, dosing, filling and vacuum sealing processes, It is the ideal packaging solution for vacuum packaging.
Product parameters
| Model | VBS-180 | VBS-180D | VBSG-180 | VBSG-180D |
| Maximum Packing Volume | 400ml | 100ml |
500ml | 100ml |
| Max Pouch Size | 180mm*200mm | 90mm*180mm |
180mm*200mm | 90mm*180mm |
| Min Pouch Size | 60mm*80mm | 50mm*80mm |
60mm*80mm | 60mm*80mm |
| Packing Speed | 40-60ppm | 100-140ppm |
40-60ppm | 100-120ppm |
| Air Consumption | 400NL/min | 400NL/min |
400NL/min | 400NL/min |
|
Input Power | 11.5kw | 11.5kw |
8.8Kw | 8.8Kw |
| Working Power Supply | AC 380V 50Hz |
AC 380V 50Hz | AC 380V 50Hz | AC 380V 50Hz |
| Equipment Weight | 2000kg | 2100kg | 1300kg | 1300kg |
| L*W*H | 5650*970*1500mm | 5650*970*1500mm | 4140*970*1390mm | 4140*970*1390mm |
| （1） Premade Pouch Stack | （2）Filp-Out Pouch-Picking Unit |
（3）Pouch Opening |
（4）Air Flushing | （5）Filling I |
| （6） Filling II | （7）Pouch Stretching |
（8）Heat Sealing |
（9）Finished Product | （10）Vacuum Pump |
